Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 4 | M-197897 | Shock Absorber Rubber Bushin |
€140,76 |
|
|
| 5 | M-183594 | Rod Circlip |
€29,07 |
|
|
| 6 | M-183595 | Shock Absorber Rod Bushing |
€43,70 |
|
|
| 8 | M-197896 | Rear Spring |
€166,60 |
|
|
| 9 | M-16044324 | Hex Head Screw M 8X55 |
€1,58 |
|
|
| 10 | M-188995 | Spring Upper Spacer D.75.5-1 |
€9,29 |
|
|
| 12 | M-183016 | Split Washer D.6.45-60 |
€18,68 |
|
|
| 15 | M-203795 | Nut. |
€4,78 |
|
|
| 17 | M-14058521 | S-Lock.Hex. Nut M8X8 |
€1,58 |
|
|
| 18 | M-163918 | Ball Joint For Control Ar |
€128,80 |
|
|
| 19 | M-13531734 | Stud M12X1.25X18 Stem |
€20,61 |
|
|
| 20 | M-387000329 | Washer 12 X 42.5 X 2.5 |
€4,36 |
|
|
| 22 | M-192996 | Toothed Brake Disc |
€204,75 |
|
|
| 23 | M-16043421 | Hex Head Screw M 8X20 |
€2,97 |
|
|
| 24 | M-10571779 | Washer |
€1,30 |
|
|
| 25 | M-197064 | Wheel Bearing With Hub |
€601,80 |
|
|
| 26 | M-183320 | Flanged Hex.Nut M28X1.5 |
€6,16 |
|
|
| 27 | M-196577 | Machined Washer D. 28.2-42 X |
€11,78 |
|
|
| 28 | M-190723 | Socket Head Screw M10X10.25. |
€15,55 |
|
|
| 29 | M-386600329 | Bushing Mount Spacer |
€21,34 |
|
|
| 30 | M-386601397 | Shim For Lower Disc Platesh. |
€4,88 |
|
|
| 31 | M-193729 | Small Link |
€67,92 |
|
|
| 33 | M-12575621 | Nylon Stop Hex. Nut M10X1.25 |
€1,58 |
|
|
| 34 | M-13550421 | Split Washer D.10.2 -20X2 |
€1,67 |
|
|
| 36 | M-397050368 | U-Bolt For Bushing |
€3,43 |
|
|
| 37 | M-10571779 | Washer |
€1,30 |
|
|
| 38 | M-16043321 | Hex Head Screw M 8X18 |
€1,30 |
|
|
| 40 | M-193733 | Rh Rear Brake Disk Cover |
€46,64 |
|
|
| 41 | M-190870 | Screw M6X14 |
€3,34 |
|
