Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-220074 | Fuel Vapor Filter |
$177.33 |
|
|
| 2 | M-188124 | Vap. Pipe From Canis. To Whe |
$26.20 |
|
|
| 3 | M-180573 | Valve With Housing |
$348.35 |
|
|
| 5 | M-189895 | Bracket For Roll Over Val |
$245.49 |
|
|
| 7 | M-12574211 | Nylon Stop Hex. Nut M6X7.8 |
$1.49 |
|
|
| 8 | M-186920 | Bracket For Vapor Caniste |
$4.49 |
|
|
| 9 | M-12574211 | Nylon Stop Hex. Nut M6X7.8 |
$1.49 |
|
|
| 11 | M-184221 | Rubber |
$3.19 |
|
|
| 12 | M-10441790 | Bracket With Sheath |
$1.10 |
|
|
| 13 | M-180861 | Washing Valve |
$91.19 |
|
|
| 14 | M-174623 | Buffer For Support |
$17.16 |
|
|
| 15 | M-187468 | Pipe From Disareator To R |
$385.68 |
|
|
| 17 | M-190518 | Underfloor Tube |
$29.13 |
|
|
| 18 | M-181703 | Washing Valve Inlet Pipe |
$8.28 |
|
|
| 19 | M-13432070 | Collar |
$1.14 |
|
|
| 20 | M-181704 | Washing Valve Outlet Pipe |
$29.70 |
|
|
| 22 | M-178430 | Cable Fastening Clip D.15 |
$117.05 |
|
|
| 23 | M-10902021 | Screw |
$1.49 |
|
|
| 24 | M-14499324 | Washer |
$1.17 |
|
|
| 25 | M-318720333 | Corrugated Pipe Int.D.16.5 E |
$7.26 |
|
|
| 26 | M-13433370 | Clamp |
$1.63 |
|
|
| 28 | M-190409 | Front Brake Pipe Retaining C |
$4.47 |
|
