| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-179140 | Cpl Power Unit |
€2.308,56 |
||
| 1 | M-179140 | Cpl Power Unit |
€2.308,56 |
||
| 1 | M-179140 | Cpl Power Unit |
€2.308,56 |
||
| 2 | M-980001155 | Ppv Valve Kit Dx0017627A |
€659,26 |
||
| 3 | M-980001154 | Qpv Valve Kit Dx0017486A |
€659,26 |
||
| 3 | M-980001154 | Qpv Valve Kit Dx0017486A |
€659,26 |
||
| 4 | M-980001156 | Ag P.U. Pressure Sensor 0016 |
€246,93 |
||
| 5 | M-185891 | Cpl Power Unit Fastening Mou |
€946,08 |
||
| 6 | M-179143 | Reservoir |
€901,60 |
||
| 7 | M-179211 | Accumulator Duct |
€205,73 |
||
| 8 | M-14058411 | Nut |
€1,35 |
||
| 9 | M-16100814 | Nut For Rear Differential |
€1,35 |
||
| 10 | M-12601374 | Washer |
€1,07 |
||
| 12 | M-16297024 | Flanged Hex Head Screw M6X18 |
€1,93 |
||
| 13 | M-184269 | Cpl Pipe From Accum.To Valve |
€94,34 |
||
| 14 | M-14301924 | Screw |
€1,93 |
||
| 14 | M-14301924 | Screw |
€1,93 |
||
| 14 | M-14301924 | Screw |
€1,93 |
||
| 15 | M-12601274 | Washer |
€1,07 |
||
| 15 | M-12601274 | Washer |
€1,07 |
||
| 15 | M-12601274 | Washer |
€1,07 |
||
| 16 | M-213264 | Hydraulic Pump |
€1.525,66 |
||
| 17 | M-185186 | Pipe From Pump To Valve Unit |
€105,59 |
||
| 18 | M-184968 | F1 Gearbox Oil Tank |
€613,78 |
||
| 19 | M-980001147 | Cpl Tank Plug F1 Kb04L0 / E |
€8,50 |
||
| 20 | M-980001148 | Oil Level Gauge Kb04R0 / E |
€60,96 |
||
| 21 | M-185952 | Gearbox Oil Tank Bracket |
€195,52 |
||
| 22 | M-980001157 | Pump Fastening Kit 0017482.A |
€265,17 |
||
| 23 | M-186298 | Tank Support Strip |
€68,20 |
||
| 24 | M-183718 | Rubber Gasket |
€12,08 |
||
| 24 | M-183718 | Rubber Gasket |
€12,08 |
||
| 25 | M-10902124 | Screw |
€1,35 |
||
| 26 | M-12601274 | Washer |
€1,07 |
||
| 27 | M-185070 | Pipe From Power Unit To Oil |
€499,62 |
||
| 28 | M-14305724 | Screw |
€1,35 |
||
| 29 | M-12601274 | Washer |
€1,07 |
||
| 30 | M-10441790 | Bracket With Sheath |
€0,87 |
||
| 31 | M-161490 | Screw Collar D.12-20X9 |
€4,06 |
||
| 31 | M-161490 | Screw Collar D.12-20X9 |
€4,06 |
||
| 31 | M-161490 | Screw Collar D.12-20X9 |
€4,06 |
||
| 32 | M-179338 | Tank Fuel Pipe To Motor-Driv |
€166,46 |
||
| 33 | M-13000390 | Screw Collar |
€1,35 |
||
| 34 | M-980001159 | P.U. Pump Union Kit Dx0017 |
€212,42 |
||
| 35 | M-188459 | Cpl Filter Oil |
€6,52 |
||
| 36 | M-14066021 | Low S-Lock.Hex.Nut With Flan |
€4,44 |
||
| 37 | M-585410200 | Studs For Head Cover And Pip |
€21,45 |
||
| 38 | M-14306524 | Screw |
€1,65 |
||
| 39 | M-10441390 | Bracket With Sheath |
€1,35 |
||
| 40 | M-12601279 | Washer |
€1,07 |
||
| 41 | M-15896214 | Nut |
€0,97 |
||
| 42 | M-162606 | Clip |
€1,93 |
||
| 42 | M-162606 | Clip |
€1,93 |
||
| 43 | M-14058411 | Nut |
€1,35 |
||
| 43 | M-14058411 | Nut |
€1,35 |
||
| 45 | M-16285924 | Screw |
€1,35 |
||
| 47 | M-12601174 | Washer |
€1,16 |
||
| 48 | M-14496324 | Split Washer D. 5.30X9.55 |
€1,74 |
||
| 49 | M-15896414 | Hex. Nut M5X4 |
€1,35 |
||
| 50 | M-186906 | Bracket |
€22,60 |
