Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 2 | M-980000966 | Rh Handle Gasket |
€34,87 |
|
|
| 5 | M-384500396 | Door Lock Handle Connect.Tie |
€6,97 |
|
|
| 6 | M-46401658 | Screw With Incorp.Washer |
€1,86 |
|
|
| 7 | M-60594692 | Rubber Bushing |
€22,17 |
|
|
| 8 | M-16284914 | Screw For Exterior Door H |
€2,09 |
|
|
| 9 | M-67237000 | Rh Door Int. Opening Bowden |
€27,42 |
|
|
| 10 | M-66132400 | Rh Safety Control Tie-Rod |
€17,85 |
|
|
| 11 | M-14572587 | Cable And Line Ret.Clip 1/5. |
€1,30 |
|
|
| 13 | M-15624311 | Rivet For Bracket On Inte |
€2,23 |
|
|
| 14 | M-67236800 | Rh Door Internal Handle |
€738,76 |
|
|
| 15 | M-388300615 | Switch |
€48,93 |
|
|
| 16 | M-82377992 | Retaining Clip |
€0,84 |
|
|
| 18 | M-60624899 | Rh Door Stopping Tie-Rod Gas |
€1,86 |
|
|
| 19 | M-11620021 | Screw For Complete Door H |
€1,86 |
|
|
| 22 | M-60584861 | Screw |
€2,97 |
|
|
| 24 | M-11586024 | Screw For Complete Door H |
€4,88 |
|
|
| 25 | M-382500536 | Hinge Plate Thick. 1Mm |
€80,41 |
|
|
| 26 | M-60624898 | Rh Door Stopping Tie-Rod Gas |
€1,86 |
|
|
| 27 | M-67420200 | White |
€1,58 |
|
|
| 28 | M-384500390 | Int.Lock Pawl Connect.Tie-Ro |
€4,76 |
|
|
| 31 | M-387700406 | Shim For Door Glass Rear Run |
€15,46 |
|
|
| 32 | M-13271617 | Tcic Pz Screw M4X6 |
€1,30 |
|
|
| 33 | M-14496207 | Split Washer D. 4.30- 9 X0 |
€1,02 |
|
|
| 35 | M-15689907 | Tbic S-Thread.Screw M8X25 |
€1,30 |
|
