Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-182778 | Rear Shock Absorber |
$1,351.30 |
|
|
| 5 | M-183594 | Rod Circlip |
$34.39 |
|
|
| 6 | M-183595 | Shock Absorber Rod Bushing |
$51.07 |
|
|
| 8 | M-163653 | Suspension Spring |
$331.75 |
|
|
| 9 | M-189507 | Spacer |
$16.74 |
|
|
| 10 | M-188995 | Spring Upper Spacer D.75.5-1 |
$10.86 |
|
|
| 12 | M-183016 | Split Washer D.6.45-60 |
$19.30 |
|
|
| 15 | M-203795 | Nut. |
$5.60 |
|
|
| 17 | M-14058521 | S-Lock.Hex. Nut M8X8 |
$1.86 |
|
|
| 18 | M-163918 | Ball Joint For Control Ar |
$151.08 |
|
|
| 19 | M-13531734 | Stud M12X1.25X18 Stem |
$24.09 |
|
|
| 20 | M-387000329 | Washer 12 X 42.5 X 2.5 |
$5.10 |
|
|
| 22 | M-192996 | Toothed Brake Disc |
$235.13 |
|
|
| 23 | M-16043421 | Hex Head Screw M 8X20 |
$3.48 |
|
|
| 24 | M-10571779 | Washer |
$1.52 |
|
|
| 25 | M-185564 | Wheel Bearing With Hub |
$1,060.09 |
|
|
| 26 | M-183320 | Flanged Hex.Nut M28X1.5 |
$7.21 |
|
|
| 27 | M-196577 | Machined Washer D. 28.2-42 X |
$13.77 |
|
|
| 28 | M-190723 | Socket Head Screw M10X10.25. |
$18.17 |
|
|
| 29 | M-386600329 | Bushing Mount Spacer |
$24.94 |
|
|
| 30 | M-386601397 | Shim For Lower Disc Platesh. |
$5.71 |
|
|
| 31 | M-193729 | Small Link |
$79.95 |
|
|
| 33 | M-12575621 | Nylon Stop Hex. Nut M10X1.25 |
$1.86 |
|
|
| 34 | M-13550421 | Split Washer D.10.2 -20X2 |
$1.95 |
|
|
| 35 | M-193662 | Bar Rubber Bushing D.16X30 |
$12.68 |
|
|
| 36 | M-397050368 | U-Bolt For Bushing |
$4.05 |
|
|
| 37 | M-10571779 | Washer |
$1.52 |
|
|
| 38 | M-16043321 | Hex Head Screw M 8X18 |
$1.34 |
|
