Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 2 | M-670030635 | Screw |
$2.06 |
|
|
| 3 | M-675000077 | Screw |
$2.26 |
|
|
| 4 | M-670007562 | Lhd Pilot Side Windshield Wi |
$163.80 |
|
|
| 5 | M-670001642 | Lhd Passenger Side Windscreen Arm |
$132.38 |
|
|
| 8 | M-675000175 | Nut |
$0.99 |
|
|
| 10 | M-670007188 | Protection Boot. |
$1.10 |
|
|
| 11 | M-675000176 | Washer |
$1.11 |
|
|
| 12 | M-670105310 | Windscreen Washer Tank |
$224.75 |
|
|
| 13 | M-670038848 | Tank Pipe |
$32.95 |
|
|
| 15 | M-670030893 | Special Washer |
$2.88 |
|
|
| 16 | M-675000049 | Air Filter |
$6.55 |
|
|
| 17 | M-670032787 | Rain Sensor |
$84.32 |
|
|
| 18 | M-670038114 | High Tone Horn |
$51.36 |
|
|
| 19 | M-670038113 | Low Tone Horn |
$51.36 |
|
|
| 20 | M-675000433 | Screw |
$1.64 |
|
|
| 21 | M-670005392 | Screw |
$3.81 |
|
|
| 30 | M-675000651 | Clip Rain Sensor |
$5.62 |
|
|
| 31 | M-673007345 | Gelpad For Sensor Rain/Humid |
$31.86 |
|
|
| 34 | M-673008176 | Lhd Wiper Set |
$67.15 |
|
