The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670031102 | Exhaust Muffler Rh Front Hea |
$41.82 |
|
|
| 2 | M-675000136 | Screw |
$2.29 |
|
|
| 4 | M-675000136 | Screw |
$2.29 |
|
|
| 5 | M-675000047 | Washer |
$5.67 |
|
|
| 6 | M-670001539 | Right Side Upper Silencer He |
$33.65 |
|
|
| 7 | M-670004544 | Rear R.H. Heat Shield |
$25.66 |
|
|
| 8 | M-670001538 | Left Side Upper Silencer Hea |
$33.65 |
|
|
| 9 | M-670001532 | Left Side Lower Silencer Hea |
$31.55 |
|
|
| 10 | M-670101040 | Front Fuel Duct Guard |
$39.54 |
|
|
| 11 | M-670037228 | Tank Heat Shield |
$83.91 |
|
|
| 12 | M-670003758 | Fixing Button |
$2.83 |
|
|
| 13 | M-675000047 | Washer |
$5.67 |
|
|
| 14 | M-675000047 | Washer |
$5.67 |
|
|
| 16 | M-675000047 | Washer |
$5.67 |
|
|
| 17 | M-675000136 | Screw |
$2.29 |
|
|
| 19 | M-675000315 | Nut |
$1.75 |
|
|
| 20 | M-670031496 | Propeller Shaft Shield |
$55.10 |
|
|
| 21 | M-670034534 | Transmission Shaft Central P |
$39.49 |
|
|
| 22 | M-670030343 | Lh Heat Shield |
$22.36 |
|
|
| 23 | M-675000047 | Washer |
$5.67 |
|
|
| 24 | M-670009348 | Lh Heat Shield |
$26.01 |
|
|
| 26 | M-670003444 | Crankshaft Rear Protection |
$32.69 |
|
