The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670002060 | R.H.Silencer Heat Shield |
$41.52 |
|
|
| 2 | M-675000136 | Screw |
$2.27 |
|
|
| 4 | M-675000136 | Screw |
$2.27 |
|
|
| 5 | M-675000047 | Washer |
$5.63 |
|
|
| 6 | M-670001539 | Right Side Upper Silencer He |
$33.42 |
|
|
| 7 | M-670001533 | Right Side Lower Silencer He |
$33.42 |
|
|
| 8 | M-670001538 | Left Side Upper Silencer Hea |
$33.42 |
|
|
| 9 | M-670001532 | Left Side Lower Silencer Hea |
$31.32 |
|
|
| 11 | M-670037228 | Tank Heat Shield |
$83.32 |
|
|
| 12 | M-670003758 | Fixing Button |
$2.81 |
|
|
| 13 | M-675000047 | Washer |
$5.63 |
|
|
| 14 | M-675000047 | Washer |
$5.63 |
|
|
| 15 | M-670005780 | L.H. Heat Shield |
$236.17 |
|
|
| 16 | M-675000047 | Washer |
$5.63 |
|
|
| 17 | M-675000136 | Screw |
$2.27 |
|
|
| 19 | M-675000315 | Nut |
$1.73 |
|
|
| 20 | M-670031496 | Propeller Shaft Shield |
$54.71 |
|
|
| 21 | M-670034534 | Transmission Shaft Central P |
$39.22 |
|
|
| 22 | M-670106027 | Shield |
$34.38 |
|
|
| 23 | M-675000047 | Washer |
$5.63 |
|
|
| 26 | M-670003444 | Crankshaft Rear Protection |
$32.46 |
|
