The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670103676 | Hot-End Ccc Dx |
$4,201.21 |
|
|
| 2 | M-670103675 | Hot-End Ccc Sx |
$3,803.63 |
|
|
| 3 | M-675000060 | Collar |
$29.64 |
|
|
| 4 | M-670001493 | Intermediate Bracket Securin |
$14.61 |
|
|
| 5 | M-670002056 | Rh Bracket |
$14.71 |
|
|
| 6 | M-670002055 | Exhaust Pipe Lh Support |
$39.38 |
|
|
| 7 | M-670001492 | Intermediate Bracket Securin |
$11.47 |
|
|
| 8 | M-675000091 | Nut |
$1.29 |
|
|
| 9 | M-675000052 | Gasket |
$8.65 |
|
|
| 10 | M-675000112 | Screw |
$2.42 |
|
|
| 11 | M-670002200 | Front Lambda Sensor |
$197.75 |
|
|
| 12 | M-670153175 | Rear Lambda Sensor |
$219.61 |
|
|
| 13 | M-670005126 | Clip |
$1.12 |
|
|
| 14 | M-670002259 | Bracket |
$6.80 |
|
|
| 15 | M-670007619 | Retaining Clip |
$1.72 |
|
|
| 16 | M-670003739 | Clip |
$2.50 |
|
|
| 17 | M-675000143 | Clip |
$0.99 |
|
|
| 18 | M-675000102 | Screw |
$2.67 |
|
