Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-289270 | Cpl Lush Adjuster With Rocke |
$33.91 |
|
|
| 2 | M-179763 | Cotter For Spring Valve |
$1.54 |
|
|
| 3 | M-287554 | Upper Spacer |
$8.58 |
|
|
| 4 | M-331715 | Spring For Valve Return |
$14.34 |
|
|
| 6 | M-221473 | Oil Seal For Valves |
$5.55 |
|
|
| 7 | M-287552 | Exhaust Lower Spacer |
$5.58 |
|
|
| 9 | M-314857 | Exhaust Valve |
$46.13 |
|
|
| 10 | M-278885 | Exhaust Valve Seat |
$9.83 |
|
|
| 11 | M-287551 | Exhaust Lower Spacer |
$5.58 |
|
|
| 13 | M-314856 | Intake Valve |
$18.03 |
|
|
| 14 | M-278886 | Intake Valve Seat |
$11.81 |
|
|
| 15 | M-278885 | Exhaust Valve Seat |
$9.83 |
|
|
| 16 | M-278886 | Intake Valve Seat |
$11.81 |
|
