Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670035635 | R.H. Intercooler |
$379.11 |
|
|
| 3 | M-670037774 | Air Shutter |
$86.63 |
|
|
| 4 | M-670009576 | Intercooler Elastic Support |
$6.58 |
|
|
| 5 | M-670009556 | Radiator Support Fastening B |
$3.18 |
|
|
| 6 | M-670037757 | Lower Intercooler Bracket |
$19.32 |
|
|
| 7 | M-670035636 | L.H. Intercooler |
$335.03 |
|
|
| 8 | M-670037775 | Secondary Air Shutter |
$86.63 |
|
|
| 9 | M-670037759 | Intercooler Bracket |
$94.73 |
|
|
| 11 | M-670105708 | Intake Air Sleeve |
$413.40 |
|
|
| 12 | M-675000288 | Spacer |
$2.25 |
|
|
| 13 | M-675000054 | Small Black |
$14.24 |
|
|
| 14 | M-675000017 | Spacer |
$8.20 |
|
|
| 15 | M-670004156 | Sleeve From Turbine To Inter |
$547.61 |
|
|
| 16 | M-675000016 | Rubber Bushing |
$5.79 |
|
|
| 17 | M-670004878 | Outlet Air Sleeve From Turbi |
$198.86 |
|
|
| 18 | M-675000017 | Spacer |
$8.20 |
|
|
| 19 | M-675000288 | Spacer |
$2.25 |
|
|
| 20 | M-675000016 | Rubber Bushing |
$5.79 |
|
|
| 21 | M-675000054 | Small Black |
$14.24 |
|
|
| 22 | M-675000288 | Spacer |
$2.25 |
|
|
| 23 | M-675000054 | Small Black |
$14.24 |
|
|
| 24 | M-675000362 | Collar |
$4.88 |
|
|
| 27 | M-670004157 | Bracket |
$30.75 |
|
|
| 28 | M-675000087 | Screw |
$3.56 |
|
|
| 29 | M-675000088 | Screw |
$2.65 |
|
|
| 30 | M-675000574 | Clamp Visa |
$2.99 |
|
|
| 31 | M-675000354 | Screw |
$2.71 |
|
|
| 35 | M-675000409 | Washer |
$2.48 |
|
|
| 36 | M-675000088 | Screw |
$2.65 |
|
|
| 37 | M-675000718 | Washer |
$2.24 |
|
