The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670032480 | Aesthetic Guard On Intake Ma |
$269.98 |
|
|
| 2 | M-670005638 | Clip |
$4.43 |
|
|
| 3 | M-675000442 | Nut |
$1.43 |
|
|
| 4 | M-675000404 | Cpl. Tv Control Station Fixi |
$1.44 |
|
|
| 5 | M-675000412 | Hex Nut |
$1.21 |
|
|
| 6 | M-670006846 | Screw |
$2.04 |
|
|
| 8 | M-675000311 | Plug |
$3.18 |
|
|
| 11 | M-670013428 | Brake Fluid Topping-Up Door |
$15.65 |
|
|
| 12 | M-670035454 | Under Windscreen Plate Reinf |
$79.55 |
|
|
| 13 | M-670004127 | Water Shield |
$15.15 |
|
|
| 14 | M-670009206 | Sleeve |
$27.23 |
|
|
| 15 | M-670005402 | Clamp |
$1.66 |
|
|
| 17 | M-670009518 | Cplunder-Windshield Water Ta |
$45.25 |
|
|
| 18 | M-675000150 | Fixing Button. |
$0.96 |
|
|
| 21 | M-673000068 | R.H. Moulding On Ceiling |
$250.47 |
|
|
| 24 | M-670004125 | Bracket |
$27.68 |
|
|
| 26 | M-940000335 | Rear Rh Protective Film Kit |
$65.08 |
|
|
| 27 | M-675000150 | Fixing Button. |
$0.96 |
|
|
| 35 | M-675000058 | Fastening Clip |
$2.76 |
|
|
| 36 | M-670003422 | Bracket |
$7.11 |
|
|
| 37 | M-675000111 | Screw |
$2.54 |
|
|
| 40 | M-675000058 | Fastening Clip |
$2.76 |
|
|
| 41 | M-670001706 | Front R.H. Mudguard Reinforc |
$52.46 |
|
|
| 45 | M-670002093 | Air Intake Compartment Gaske |
$41.37 |
|
|
| 46 | M-673000064 | Light Plate |
$57.14 |
|
|
| 48 | M-673000065 | Microswitch |
$112.92 |
|
|
| 49 | M-673000066 | Fixing Element |
$60.69 |
|
|
| 53 | M-673003779 | Pin |
$3.60 |
|
|
| 54 | M-673002766 | Oil Disptik Cover And Clip ( |
$55.34 |
|
