The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-673006246 | Complete Central Floor M156 |
€1.552,04 |
|
|
| 3 | M-670006640 | Underfloor Tunnel Rear Reinf |
€78,20 |
|
|
| 4 | M-673000416 | Rh Underfloor Small Side Mem |
€52,02 |
|
|
| 5 | M-673000418 | Lh Underfloor Small Side Mem |
€37,37 |
|
|
| 6 | M-675000412 | Hex Nut |
€1,08 |
|
|
| 8 | M-670006214 | Sticker Cap |
€2,16 |
|
|
| 9 | M-670003751 | Rh Plate |
€44,53 |
|
|
| 10 | M-670003900 | Lh Plate |
€44,80 |
|
|
| 11 | M-673004077 | Underfloor Bracket Rear Tunn |
€167,44 |
|
|
| 13 | M-670031919 | Reinforcement Dx |
€12,61 |
|
|
| 14 | M-670031920 | Reinforcement Dx |
€12,61 |
|
|
| 17 | M-675000622 | Rivet |
€2,27 |
|
|
| 18 | M-675000789 | Protective Film |
€2,49 |
|
