Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670004602 | Complete Filter Housing |
$174.37 |
|
|
| 2 | M-670004604 | Diesel Air Filter |
$78.83 |
|
|
| 3 | M-675000295 | Screw |
$1.51 |
|
|
| 4 | M-670006753 | Filter Bracket |
$28.60 |
|
|
| 5 | M-675000284 | Flexible Pad |
$10.71 |
|
|
| 6 | M-675000018 | Rubber Bushing |
$4.97 |
|
|
| 7 | M-670004643 | Intake Air Sleeve Deb. Side |
$136.17 |
|
|
| 8 | M-670004599 | Dirty Air Sleeve |
$37.09 |
|
|
| 9 | M-670106061 | Clean Air Sleeve - Second Se |
$242.95 |
|
|
| 10 | M-670007158 | Gasket |
$48.99 |
|
|
| 12 | M-675000329 | O.R. Gasket |
$3.10 |
|
|
| 13 | M-670005091 | Flowmeter |
$218.05 |
|
|
| 14 | M-675000394 | Pin |
$4.15 |
|
|
| 15 | M-675000504 | Screw |
$1.11 |
|
|
| 16 | M-675000477 | Hose Collar |
$4.11 |
|
|
| 17 | M-675000476 | Hose Fastening Collar |
$2.78 |
|
|
| 18 | M-14059214 | Nut |
$1.27 |
|
|
| 19 | M-675000826 | Hex Head Screw |
$1.36 |
|
|
| 20 | M-675000825 | Washer |
$1.65 |
|
