The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-980139372 | Cpl. Cd Compartment |
$145.68 |
|
|
| 4 | M-67489800 | Cd Compartment Door. |
$159.01 |
|
|
| 5 | M-66736200 | Glove Comp.Door Endoftravel |
$80.18 |
|
|
| 6 | M-67489600 | Cd Support Bracket |
$198.00 |
|
|
| 7 | M-980139373 | Complete Door Movement Kit. |
$39.56 |
|
|
| 8 | M-67490000 | Under Steer.Wheel Compartment |
$73.78 |
|
|
| 9 | M-67575200 | Pocket Change Comp.Carpet |
$18.38 |
|
|
| 12 | M-192522 | Audiopilot Microphone. |
$68.56 |
|
|
| 13 | M-68462500 | Screw |
$1.86 |
|
|
| 15 | M-14059211 | Nut |
$1.44 |
|
|
| 16 | M-239090 | Bracket (My2009) |
$29.34 |
|
|
| 17 | M-14059211 | Nut |
$1.44 |
|
|
| 18 | M-14039414 | Nut For Third Brake Light |
$1.47 |
|
