The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-980139372 | Cpl. Cd Compartment |
$152.46 |
|
|
| 4 | M-67489800 | Cd Compartment Door. |
$166.41 |
|
|
| 5 | M-66736200 | Glove Comp.Door Endoftravel |
$83.90 |
|
|
| 6 | M-67489600 | Cd Support Bracket |
$207.21 |
|
|
| 7 | M-980139373 | Complete Door Movement Kit. |
$41.41 |
|
|
| 8 | M-67490000 | Under Steer.Wheel Compartment |
$77.21 |
|
|
| 9 | M-67575200 | Pocket Change Comp.Carpet |
$19.23 |
|
|
| 12 | M-192522 | Audiopilot Microphone. |
$71.75 |
|
|
| 13 | M-68462500 | Screw |
$1.95 |
|
|
| 15 | M-14059211 | Nut |
$1.50 |
|
|
| 16 | M-239090 | Bracket (My2009) |
$30.71 |
|
|
| 17 | M-14059211 | Nut |
$1.50 |
|
|
| 18 | M-14039414 | Nut For Third Brake Light |
$1.55 |
|
