Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 4 | M-259572 | Ball Tie Rod |
€72,17 |
|
|
| 5 | M-199126 | Front Anti-Roll Bar. |
€166,60 |
|
|
| 6 | M-199224 | Bar Buffer |
€14,50 |
|
|
| 7 | M-271290 | Upper Support For Anti-Roll |
€7,74 |
|
|
| 8 | M-271288 | Lower Support For Anti-Roll |
€5,53 |
|
|
| 9 | M-14307534 | Screw |
€7,59 |
|
|
| 10 | M-12604574 | Washer |
€1,18 |
|
|
| 11 | M-102742 | Nut. |
€1,49 |
|
|
| 12 | M-12601474 | Washer |
€1,18 |
|
|
| 13 | M-198405 | Air Flow Flap. |
€9,65 |
|
|
| 14 | M-202013 | Screw. |
€7,40 |
|
|
| 15 | M-386600416 | Joint Upper Protection |
€4,97 |
|
|
| 16 | M-386600416 | Joint Upper Protection |
€4,97 |
|
|
| 17 | M-245240 | Nut |
€9,67 |
|
|
| 19 | M-247308 | Nut For Suspension Lever Adj |
€10,30 |
|
|
| 21 | M-15977934 | Screw -Valid For Usa And Cdn |
€8,90 |
|
|
| 22 | M-13550634 | Washer. |
€3,18 |
|
|
| 23 | M-240876 | Screw |
€104,88 |
|
|
| 24 | M-203795 | Nut. |
€4,88 |
|
|
| 25 | M-240877 | Washer |
€5,34 |
|
|
| 26 | M-295191 | Distanz Di Spess Sp 125 X Vi |
€3,43 |
|
|
| 27 | M-188629 | Tie Rod For Light Adjusting |
€27,51 |
|
|
| 28 | M-102741 | Nut |
€1,49 |
|
|
| 29 | M-14498824 | Washer. |
€1,49 |
|
|
| 30 | M-980139889 | Silent Block Kit Front Suspe |
€483,00 |
|
