Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 2 | M-16043424 | Screw |
$3.97 |
|
|
| 3 | M-11198074 | Tapered Rubber Washer D8.5-1 |
$1.37 |
|
|
| 4 | M-10519624 | Washer |
$1.74 |
|
|
| 6 | M-13793021 | Screw Sete/Econ M 6X 12 |
$9.50 |
|
|
| 7 | M-205698 | Spacer For Parking Brake Cab |
$59.36 |
|
|
| 8 | M-204413 | Rubber Spacer |
$5.79 |
|
|
| 9 | M-193766 | Parking Brake Rear Cable |
$111.28 |
|
|
| 11 | M-118553 | Plate. |
$18.44 |
|
|
| 12 | M-16100814 | Nut For Rear Differential |
$1.74 |
|
|
| 13 | M-14496524 | Washer |
$1.74 |
|
|
| 14 | M-104895 | Return Spring For Brake Peda |
$4.28 |
|
|
| 16 | M-14048111 | Nut |
$1.36 |
|
|
| 17 | M-12644424 | Washer |
$1.39 |
|
|
| 18 | M-206432 | Cylindr. Pad D.9-27X11 |
$29.50 |
|
|
| 19 | M-206073 | Spacer |
$3.44 |
|
|
| 20 | M-205628 | Bracket |
$39.72 |
|
|
| 21 | M-10902524 | Screw |
$1.74 |
|
|
| 22 | M-12644424 | Washer |
$1.39 |
|
|
| 23 | M-207269 | Heat Shield |
$2.81 |
|
|
| 24 | M-206432 | Cylindr. Pad D.9-27X11 |
$29.50 |
|
|
| 25 | M-206073 | Spacer |
$3.44 |
|
|
| 26 | M-206489 | R.H.Spring For Hand-Brake Ca |
$3.14 |
|
|
| 27 | M-206488 | L.H.Spring For Hand-Brake Ca |
$3.79 |
|
|
| 28 | M-184519 | Rubber Pad |
$2.45 |
|
|
| 29 | M-200989 | Parking Brake Cable Spring |
$2.05 |
|
|
| 30 | M-14040614 | Nut |
$1.74 |
|
|
| 31 | M-143938 | Stop Sheath |
$26.27 |
|
|
| 32 | M-186574 | Brake Shoe Housing |
$75.19 |
|
|
| 33 | M-190814 | Reaction Small Plate D.I.H. |
$73.01 |
|
|
| 34 | M-190870 | Screw M6X14 |
$4.08 |
|
|
| 35 | M-248418 | Hand Brake Shoe With Lining |
$136.74 |
|
|
| 36 | M-186572 | Adjustment Device |
$104.46 |
|
|
| 37 | M-190776 | Long Traction Spring |
$25.68 |
|
|
| 38 | M-190779 | Short Traction Spring |
$69.57 |
|
|
| 39 | M-190780 | Fastening Spring |
$7.11 |
|
|
| 40 | M-980145862 | Parking Brake Lever |
$165.16 |
|
