Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 3 | M-201046 | Silent Block D35Xl28Xl40.5 |
$63.90 |
|
|
| 6 | M-259572 | Ball Tie Rod |
$83.08 |
|
|
| 7 | M-199126 | Front Anti-Roll Bar. |
$191.81 |
|
|
| 8 | M-199224 | Bar Buffer |
$16.69 |
|
|
| 9 | M-271290 | Upper Support For Anti-Roll |
$8.91 |
|
|
| 10 | M-271288 | Lower Support For Anti-Roll |
$6.36 |
|
|
| 11 | M-14307534 | Screw |
$8.74 |
|
|
| 12 | M-12604574 | Washer |
$1.36 |
|
|
| 13 | M-102742 | Nut. |
$1.72 |
|
|
| 14 | M-12601474 | Washer |
$1.36 |
|
|
| 15 | M-198405 | Air Flow Flap. |
$11.11 |
|
|
| 16 | M-202013 | Screw. |
$8.52 |
|
|
| 17 | M-386600416 | Joint Upper Protection |
$5.72 |
|
|
| 18 | M-386600416 | Joint Upper Protection |
$5.72 |
|
|
| 19 | M-149807 | Nut |
$2.60 |
|
|
| 20 | M-12646924 | Washer. |
$1.96 |
|
|
| 21 | M-247308 | Nut For Suspension Lever Adj |
$11.86 |
|
|
| 22 | M-205496 | Washer. |
$17.92 |
|
|
| 23 | M-15541334 | Screw. |
$5.02 |
|
|
| 24 | M-102825 | Nut. |
$2.12 |
|
|
| 26 | M-211689 | Shim 0.20 Spacer For Screw |
$1.76 |
|
|
| 27 | M-194444 | Washer |
$2.93 |
|
|
| 28 | M-194221 | Screw With Eccentric |
$64.02 |
|
|
| 29 | M-203795 | Nut. |
$5.61 |
|
|
| 30 | M-194222 | Eccentric Washer |
$49.37 |
|
|
| 31 | M-295191 | Distanz Di Spess Sp 125 X Vi |
$3.95 |
|
|
| 32 | M-194445 | Washer |
$3.66 |
|
|
| 33 | M-188629 | Tie Rod For Light Adjusting |
$31.67 |
|
|
| 34 | M-102741 | Nut |
$1.72 |
|
|
| 35 | M-14498824 | Washer. |
$1.72 |
|
