The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-207700 | Clutch D.215 With Double Tab |
$1,393.60 |
|
|
| 2 | M-980001166 | Clutch Balancing Kit |
$2,519.89 |
|
|
| 3 | M-230426 | Complete Engine Flywheel |
$799.01 |
|
|
| 4 | M-215963 | Washer |
$6.39 |
|
|
| 5 | M-201755 | Screw |
$2.90 |
|
|
| 6 | M-185206 | Socket Head Screw M6X60 |
$4.38 |
|
|
| 7 | M-11194377 | Washer |
$1.67 |
|
|
| 8 | M-182952 | Bearing Support Flange |
$555.58 |
|
|
| 9 | M-234953 | S.Centr.Clut.Thrust Bear. W. |
$685.68 |
|
|
| 10 | M-181837 | Scraper Ring D.33 |
$29.26 |
|
|
| 11 | M-170416 | Sliding Ring D.33 |
$3.09 |
|
|
| 12 | M-181838 | Sealing Ring D.33 |
$28.42 |
|
|
| 13 | M-181828 | Sealing Ring D=44 |
$34.61 |
|
|
| 14 | M-154507 | Sliding Ring D.44 |
$6.50 |
|
|
| 15 | M-181836 | Scraper Ring D.44 |
$32.53 |
|
|
| 16 | M-155207 | Pressure Plate Preload Sprin |
$18.06 |
|
|
| 17 | M-155206 | Spacer For Thrust Bearing Sp |
$25.05 |
|
|
| 19 | M-14305334 | Socket Head Screw M 6X 20 |
$5.47 |
|
|
| 20 | M-12604274 | Washer |
$1.48 |
|
|
| 21 | M-980139052 | Pressure Die-Cast Clutch Hou |
$3,031.49 |
|
|
| 22 | M-144511 | Stop Ring D. 72 For Hole |
$2.41 |
|
|
| 23 | M-174470 | Grooved Ball Bearing D.35-72 |
$54.26 |
|
|
| 24 | M-182963 | Stop Ring D.35 For Shaft |
$7.18 |
|
|
| 25 | M-182587 | Clutch Shaft |
$293.77 |
|
|
| 26 | M-207449 | Cpl Pipe Clutch Hyd.Ctrloil |
$265.70 |
|
|
| 27 | M-207449 | Cpl Pipe Clutch Hyd.Ctrloil |
$265.70 |
|
|
| 28 | M-13547334 | Stud M10X1.25X20 Stem |
$15.42 |
|
|
| 29 | M-14305434 | Socket Head Screw M 6X 25 |
$1.32 |
|
|
| 30 | M-12604274 | Washer |
$1.48 |
|
|
| 31 | M-139471 | 2-Way Union M12X1Clutch Pipe |
$128.57 |
|
|
| 32 | M-166676 | Pin On Clutch Supp.Mounting |
$62.85 |
|
|
| 33 | M-14158570 | Elastic Pin D.2X12 |
$1.69 |
|
|
| 34 | M-165676 | Inside Mount Magnet |
$52.45 |
|
|
| 35 | M-165658 | O-Ring I.D.2.57 C.D.1.7 |
$14.89 |
|
|
| 36 | M-167802 | Sensor Mount Plug |
$57.02 |
|
|
| 37 | M-121699 | Bleeding Screw With Cap |
$18.16 |
|
|
| 38 | M-13546334 | Stud M10X1.25X20 Stem |
$2.39 |
|
|
| 39 | M-102725 | Centring Dowel D.8X8 |
$1.68 |
|
|
| 40 | M-16286224 | Flanged Hex Head Screw M6X25 |
$2.39 |
|
|
| 41 | M-182955 | End-O-Str.Stud For Hydr.Clut |
$25.70 |
|
|
| 42 | M-12601274 | Washer |
$1.34 |
|
|
| 43 | M-14059421 | Nut |
$1.55 |
|
|
| 44 | M-191395 | Balancing Mass |
$111.42 |
|
