Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 2 | M-187815 | Rh Cylinder Head Cover |
$413.06 |
|
|
| 3 | M-198927 | Rh Head Cover Gasket |
$55.15 |
|
|
| 4 | M-14304424 | Socket Head Screw M 5X 25 |
$3.81 |
|
|
| 5 | M-14497878 | Split Washer D. 5.30X9.55 |
$1.03 |
|
|
| 6 | M-185276 | Rh Wiring Small Cover |
$47.06 |
|
|
| 7 | M-156830 | Socket Head Screw M 6X 40 |
$3.81 |
|
|
| 8 | M-200414 | Stud M6X25.5(M)-M6X11(F) |
$13.21 |
|
|
| 9 | M-198307 | Stud M6X41(M)-M6X11(F) H |
$80.56 |
|
|
| 10 | M-11197774 | Washer |
$2.17 |
|
|
| 11 | M-204102 | Stud M6X25(M)-M6X10(M) H |
$13.82 |
|
|
| 12 | M-184966 | Rh Head Gasketcrankcase |
$75.78 |
|
|
| 13 | M-14326001 | Threaded Plug For Gearbox |
$1.10 |
|
|
| 15 | M-183447 | Tapered Threaded Plug M18X1. |
$6.29 |
|
|
| 16 | M-187706 | Spark Plug Sleeve Gasket |
$4.49 |
|
|
| 17 | M-164400 | Tapered Threaded Plug D.16X1 |
$6.45 |
|
|
| 18 | M-13541224 | Stud M6X12 Stem 22 |
$42.28 |
|
|
| 19 | M-199760 | Tapered Threaded Plug 6X1 |
$1.48 |
|
|
| 20 | M-134233 | O-Ring D. D. 18.77- 8X 100 |
$7.02 |
|
|
| 21 | M-102725 | Centring Dowel D.8X8 |
$1.68 |
|
|
| 22 | M-15896211 | Nut |
$1.05 |
|
|
| 23 | M-11197774 | Washer |
$2.17 |
|
|
| 26 | M-13543424 | Stud M8X16 Stem 28 |
$1.67 |
|
|
| 27 | M-187963 | Plug |
$5.01 |
|
|
| 28 | M-184681 | Oil Pressure Check Valve |
$90.89 |
|
|
| 30 | M-10263360 | Gasket 20- 26X 1 |
$0.96 |
|
|
| 31 | M-14305621 | Screw |
$1.67 |
|
