The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670156049 | Rh Front Upper Lever Assembl |
$521.16 |
|
|
| 2 | M-670160347 | Bushing |
$78.25 |
|
|
| 3 | M-675000051 | Screw ˇ |
$2.72 |
|
|
| 4 | M-675001345 | Screw |
$2.26 |
|
|
| 5 | M-670160337 | Bushing |
$180.25 |
|
|
| 6 | M-675001196 | Screw |
$9.88 |
|
|
| 9 | M-670002744 | Small Link For Bar |
$57.72 |
|
|
| 10 | M-670160647 | Screw |
$4.90 |
|
|
| 11 | M-675000184 | Nut |
$1.79 |
|
|
| 12 | M-670181110 | Front Stabilizer Bar |
$361.48 |
|
|
| 13 | M-675000393 | Screw |
$4.10 |
|
|
| 14 | M-670156095 | Rh Front Swinging Arm |
$325.24 |
|
|
| 15 | M-670160622 | Screw |
$98.74 |
|
|
| 16 | M-670174098 | Washer |
$18.56 |
|
|
| 17 | M-675000023 | Nut |
$1.40 |
|
|
| 18 | M-675001188 | Nut |
$5.73 |
|
|
| 19 | M-670160632 | Spacer |
$18.00 |
|
|
| 20 | M-670160354 | Lh Axle Rod |
$258.62 |
|
|
| 21 | M-670160335 | Camber Adjustment Plate Thic |
$10.43 |
|
|
| 22 | M-670213189 | Washer |
$1.26 |
|
|
| 23 | M-673013880 | Kit Camber Adjustment Plates |
$1,240.21 |
|
