Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670156485 | Tank Heat Shield |
$182.69 |
|
|
| 2 | M-670003758 | Fixing Button |
$2.80 |
|
|
| 3 | M-670218891 | Silencer Heat Shield |
$222.94 |
|
|
| 4 | M-675000278 | Screw |
$1.53 |
|
|
| 5 | M-675001245 | Screw |
$1.63 |
|
|
| 6 | M-670160119 | Gearbox Heat Repair |
$46.28 |
|
|
| 7 | M-670175152 | Nut |
$2.96 |
|
|
| 8 | M-670175146 | Washer |
$2.58 |
|
|
| 9 | M-670175147 | Screw |
$6.84 |
|
|
| 10 | M-670160342 | Rh Axle Shaft Shield |
$44.23 |
|
|
| 11 | M-670160344 | Lh Axle Shaft Shield |
$50.43 |
|
|
| 12 | M-675001384 | Screw |
$1.39 |
|
|
| 13 | M-670213181 | Heat Shield |
$56.20 |
|
|
| 14 | M-670213182 | Heat Shield |
$49.20 |
|
|
| 15 | M-670213184 | Heat Shield |
$49.20 |
|
|
| 16 | M-670213185 | Heat Shield |
$48.71 |
|
|
| 17 | M-670213186 | Heat Shield |
$49.20 |
|
|
| 18 | M-670213187 | Heat Shield |
$56.20 |
|
|
| 19 | M-670213183 | Heat Shield |
$48.71 |
|
|
| 20 | M-670213178 | Clamp |
$5.72 |
|
