Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670177054 | Rh External Door Handle Brac |
€119,60 |
|
|
| 2 | M-670158113 | Rh Door Lock Lhd |
€177,56 |
|
|
| 3 | M-675000573 | Doors Lock Striker |
€15,18 |
|
|
| 4 | M-670216113 | Front Rh Power Window Mechan |
€455,80 |
|
|
| 5 | M-670156863 | Rh Upper Hinge |
€1.337,68 |
|
|
| 6 | M-675001336 | Screw |
€2,64 |
|
|
| 7 | M-670293468 | Rh/Lh Gas Spring |
€189,52 |
|
|
| 8 | M-675001430 | Washer |
€1,40 |
|
|
| 9 | M-675001041 | Screw |
€27,23 |
|
|
| 10 | M-670173527 | Bracket |
€37,17 |
|
|
| 12 | M-670177384 | Opening/Closening Device |
€132,48 |
|
|
| 14 | M-670215414 | Pin |
€41,77 |
|
|
| 15 | M-675001442 | Washer |
€4,18 |
|
|
| 16 | M-670006484 | Screw |
€1,46 |
|
|
| 17 | M-675001355 | Screw |
€1,88 |
|
