The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670156453 | R.H. Front Air Duct |
$39.51 |
|
|
| 2 | M-670156454 | L.H Front Air Duct |
$39.51 |
|
|
| 3 | M-670156452 | Connector Hvac Module |
$167.95 |
|
|
| 4 | M-670156451 | Rh Side Air Duct Assembly |
$39.51 |
|
|
| 6 | M-670156450 | Lh Side Air Duct Assembly |
$39.51 |
|
|
| 7 | M-670160888 | R.H. Front Air Duct |
$39.51 |
|
|
| 8 | M-670160887 | L.H Front Air Duct |
$39.51 |
|
|
| 10 | M-670161955 | Lh Side Air Duct |
$39.51 |
|
|
| 18 | M-670161959 | Air Vent Duct Rear Union |
$11.45 |
|
|
| 19 | M-675001294 | Screw Hsh |
$1.77 |
|
|
| 20 | M-670006373 | Screw |
$2.08 |
|
|
| 22 | M-675001266 | Pin |
$2.63 |
|
