The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670212790 | L.H. Intercooler |
$918.52 |
|
|
| 2 | M-670212793 | R.H. Intercooler |
$918.52 |
|
|
| 3 | M-675001211 | Screw |
$6.85 |
|
|
| 4 | M-670215624 | Lh Side Air Duct |
$230.35 |
|
|
| 5 | M-670215625 | Rh Side Air Duct |
$230.35 |
|
|
| 6 | M-675001063 | Nut |
$1.22 |
|
|
| 7 | M-675001357 | Screw |
$3.92 |
|
|
| 8 | M-670293049 | Lh Sleeve |
$174.45 |
|
|
| 9 | M-670293054 | Rh Sleeve |
$174.45 |
|
|
| 10 | M-670053933 | Air Temp Sensor |
$92.21 |
|
|
| 11 | M-675000362 | Collar |
$4.80 |
|
|
| 12 | M-670292987 | Intercooler Sleeve |
$254.45 |
|
|
| 13 | M-675001051 | Modular Solenoid Valve |
$73.96 |
|
|
| 14 | M-675001353 | Screw |
$2.59 |
|
|
| 15 | M-670157013 | Lh Air Intake Sleeve Assembl |
$81.02 |
|
|
| 16 | M-670157012 | Rh Air Intake Sleeve Assembl |
$81.02 |
|
|
| 17 | M-675001354 | Collar |
$1.46 |
|
|
| 18 | M-670181764 | Lh Clean Air Intake Sleeve |
$407.69 |
|
|
| 19 | M-670181761 | Rh Clean Air Intake Sleeve |
$407.69 |
|
|
| 20 | M-675001034 | Screw |
$1.64 |
|
|
| 21 | M-670213188 | Bracket |
$18.14 |
|
|
| 22 | M-670051107 | Screw |
$1.85 |
|
|
| 24 | M-675001427 | Nut M5 |
$0.71 |
|
|
| 25 | M-670051103 | Screw |
$2.59 |
|
|
| 26 | M-675000754 | Collar |
$5.64 |
|
|
| 27 | M-675001961 | Gasket |
$27.85 |
|
