Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670156049 | Rh Front Upper Lever Assembl |
$527.13 |
|
|
| 2 | M-670160347 | Bushing |
$79.15 |
|
|
| 3 | M-675000051 | Screw ˇ |
$2.76 |
|
|
| 4 | M-675001345 | Screw |
$2.28 |
|
|
| 5 | M-670160337 | Bushing |
$182.32 |
|
|
| 6 | M-675001196 | Screw |
$10.00 |
|
|
| 8 | M-675001194 | Nut |
$8.90 |
|
|
| 9 | M-670002744 | Small Link For Bar |
$58.38 |
|
|
| 10 | M-670160647 | Screw |
$4.95 |
|
|
| 11 | M-675000184 | Nut |
$1.81 |
|
|
| 12 | M-670181110 | Front Stabilizer Bar |
$365.62 |
|
|
| 13 | M-675000393 | Screw |
$4.15 |
|
|
| 14 | M-670156095 | Rh Front Swinging Arm |
$328.96 |
|
|
| 15 | M-670160622 | Screw |
$99.87 |
|
|
| 16 | M-670174098 | Washer |
$18.77 |
|
|
| 17 | M-675000023 | Nut |
$1.42 |
|
|
| 18 | M-675001188 | Nut |
$5.79 |
|
|
| 19 | M-670160632 | Spacer |
$18.21 |
|
|
| 20 | M-670160354 | Lh Axle Rod |
$261.58 |
|
|
| 21 | M-670160335 | Camber Adjustment Plate Thic |
$10.55 |
|
|
| 22 | M-670213189 | Washer |
$1.28 |
|
|
| 23 | M-673013880 | Kit Camber Adjustment Plates |
$1,254.41 |
|
