The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670162142 | Rear Brake Disc |
$3,757.69 |
|
|
| 2 | M-675000081 |
Screw
|
$4.97 |
|
|
| 3 | M-670220160 | Brake Disc Shield |
$53.72 |
|
|
| 4 | M-675001032 | Screw |
$1.25 |
|
|
| 6 | M-675001192 | Screw |
$4.92 |
|
|
| 7 | M-670156282 | Pipe |
$10.61 |
|
|
| 8 | M-670212954 | Bracket |
$42.89 |
|
|
| 9 | M-675001159 | Screw |
$4.15 |
|
|
| 10 | M-675000276 | Plate |
$0.95 |
|
|
| 11 | M-673012307 | Mc20 Rear Brake Pads Kit |
$1,369.66 |
|
|
| 12 | M-673010935 | Rh Bracket And Screw |
$45.46 |
|
|
| 14 | M-673001646 | Bleeder Screw |
$29.72 |
|
|
| 15 | M-673010932 | Spring And Pins Kit |
$110.83 |
|
