Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670156516 | Lh Filter Box Assembly |
$463.36 |
|
|
| 2 | M-670156515 | Rh Filter Box Assembly |
$463.36 |
|
|
| 3 | M-673011137 | MC20 Air Filter Kit Intake Engine |
$190.16 |
|
|
| 4 | M-670156523 | Lh Clean Air Intake Sleeve |
$67.84 |
|
|
| 5 | M-670156522 | Rh Clean Air Intake Sleeve |
$67.84 |
|
|
| 6 | M-670175709 | Fixing Collar |
$8.38 |
|
|
| 7 | M-670156583 | Lh Bracket |
$113.45 |
|
|
| 8 | M-670157263 | Rh Bracket |
$111.33 |
|
|
| 9 | M-675001212 | Screw |
$2.17 |
|
|
| 10 | M-675001257 | Washer 6X18 |
$1.70 |
|
|
| 11 | M-670215627 | Rh Cooling Engine Manifold |
$199.84 |
|
|
| 12 | M-670215629 | Lh Cooling Engine Manifold |
$228.25 |
|
|
| 13 | M-670214223 | Screw |
$3.07 |
|
