Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670053770 | Complete Timing Cover |
$1,668.00 |
|
|
| 2 | M-670051267 | Gasket |
$31.60 |
|
|
| 3 | M-670050460 | Bearing |
$237.45 |
|
|
| 4 | M-670051042 | Bearing Plate |
$10.46 |
|
|
| 5 | M-670050026 | Screw |
$2.61 |
|
|
| 7 | M-670051115 | Screw |
$2.21 |
|
|
| 8 | M-670051111 | Screw |
$2.06 |
|
|
| 9 | M-670053347 | Timing Control Assy |
$855.29 |
|
|
| 10 | M-670053926 | Crankshaft Gear |
$252.05 |
|
|
| 11 | M-670053953 | Crankshaft Gear |
$235.51 |
|
|
| 12 | M-670050184 | Support |
$94.58 |
|
|
| 13 | M-670050416 | O-Ring |
$2.53 |
|
|
| 14 | M-670050158 | Screw |
$8.00 |
|
|
| 15 | M-670050109 | Bearing Cage |
$13.30 |
|
|
| 16 | M-670050185 | Bearing Spacer |
$15.01 |
|
|
| 17 | M-670050158 | Screw |
$8.00 |
|
|
| 18 | M-670050993 | Spacer |
$1.85 |
|
|
| 19 | M-670053475 | Variable Valve Actuator |
$90.52 |
|
|
| 20 | M-670051106 | Screw |
$2.31 |
|
|
| 21 | M-670053954 | Oil Pump Gear |
$77.96 |
|
|
| 22 | M-670050159 | Screw |
$5.07 |
|
|
| 23 | M-670050999 | Gasket |
$2.76 |
|
|
| 24 | M-670050150 | Screw |
$2.61 |
|
|
| 25 | M-670050020 | Screw |
$2.61 |
|
|
| 26 | M-670050148 | Screw |
$2.61 |
|
|
| 27 | M-670050147 | Screw |
$2.61 |
|
|
| 28 | M-670050149 | Screw |
$2.61 |
|
|
| 29 | M-670051123 | Gasket |
$7.82 |
|
|
| 30 | M-670050141 | Rivet |
$23.99 |
|
|
| 31 | M-675001406 | Stud |
$4.02 |
|
|
| 32 | M-670053939 | Bar |
$326.01 |
|
|
| 33 | M-670051322 | Washer |
$2.35 |
|
|
| 34 | M-670053870 | Screw |
$4.83 |
|
|
| 36 | M-670050140 | Rivet |
$22.09 |
|
