The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 3 | M-675001294 | Screw Hsh |
$1.82 |
|
|
| 9 | M-670161011 | Hinge |
$95.49 |
|
|
| 12 | M-670160893 | Bracket |
$65.83 |
|
|
| 13 | M-670006373 | Screw |
$2.13 |
|
|
| 15 | M-670172800 | Bracket |
$46.43 |
|
|
| 17 | M-670161130 | Brace Latch |
$14.87 |
|
|
| 19 | M-670161131 | Bracket |
$14.00 |
|
|
| 20 | M-670161963 | Console Bracket |
$10.00 |
|
|
| 21 | M-670161962 | Bracket |
$39.74 |
|
|
| 22 | M-670160894 | Fixing Bracket |
$138.35 |
|
|
| 23 | M-670156099 | Bracket |
$54.15 |
|
|
| 26 | M-670162175 | Bracket |
$47.18 |
|
|
| 27 | M-670035713 | Fastening Screw |
$1.75 |
|
|
| 28 | M-675001050 | Screw |
$1.45 |
|
|
| 29 | M-675001340 | Screw |
$0.87 |
|
|
| 30 | M-670174643 | Screw |
$8.11 |
|
|
| 31 | M-670174644 | Screw |
$7.11 |
|
