Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670177054 | Rh External Door Handle Brac |
$124.06 |
|
|
| 2 | M-670158113 | Rh Door Lock Lhd |
$204.64 |
|
|
| 3 | M-675000573 | Doors Lock Striker |
$18.03 |
|
|
| 4 | M-670216113 | Front Rh Power Window Mechan |
$544.14 |
|
|
| 5 | M-670156863 | Rh Upper Hinge |
$1,387.93 |
|
|
| 6 | M-675001336 | Screw |
$3.16 |
|
|
| 7 | M-670293468 | Rh/Lh Gas Spring |
$225.84 |
|
|
| 8 | M-675001430 | Washer |
$1.69 |
|
|
| 9 | M-675001041 | Screw |
$32.33 |
|
|
| 10 | M-670173527 | Bracket |
$44.34 |
|
|
| 12 | M-670177384 | Opening/Closening Device |
$159.05 |
|
|
| 14 | M-670215414 | Pin |
$49.59 |
|
|
| 15 | M-675001442 | Washer |
$5.04 |
|
|
| 16 | M-670006484 | Screw |
$1.73 |
|
|
| 17 | M-675001355 | Screw |
$2.25 |
|
