The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670181599 | Cpl Rh Catalytic Converter |
$4,487.05 |
|
|
| 2 | M-670181597 | Cpl Lh Catalytic Converter |
$4,487.05 |
|
|
| 3 | M-670181543 | Rh Catalytic Converter With |
$3,037.67 |
|
|
| 4 | M-670181548 | Lh Catalytic Converter With |
$3,037.67 |
|
|
| 5 | M-670172811 | Rear Lambda Sensor |
$276.19 |
|
|
| 6 | M-675001146 | Upper Lambda Sensor |
$104.53 |
|
|
| 7 | M-670176379 | Rh Bracket |
$63.62 |
|
|
| 8 | M-670176380 | Lh Bracket |
$63.62 |
|
|
| 9 | M-670051105 | Screw |
$2.35 |
|
|
| 10 | M-675001026 | Collar |
$15.56 |
|
|
| 11 | M-675001244 | Collar |
$12.99 |
|
|
| 12 | M-670160485 | Exhaust Bracket |
$210.31 |
|
|
| 13 | M-675001243 | Screw |
$17.17 |
|
|
| 14 | M-675001242 | Screw |
$3.87 |
|
|
| 15 | M-675000278 | Screw |
$1.52 |
|
|
| 16 | M-675000257 | Screw |
$5.89 |
|
|
| 17 | M-670161480 | Screw |
$36.01 |
|
|
| 18 | M-670160495 | Exhaust Pipe Support Bracket |
$177.48 |
|
|
| 19 | M-670156590 | Lh Bracket |
$97.87 |
|
|
| 20 | M-670156591 | Rh Bracket |
$97.87 |
|
|
| 21 | M-670213038 | Screw |
$9.56 |
|
|
| 22 | M-675000779 | Nut |
$2.77 |
|
|
| 23 | M-675001248 | Gasket |
$31.01 |
|
|
| 24 | M-675001247 | Gasket |
$13.17 |
|
|
| 25 | M-670156620 | Rh Pipe Assembly |
$13.50 |
|
|
| 26 | M-670156621 | Rh Pipe Assembly |
$13.37 |
|
|
| 27 | M-670157261 | Lh Pipe Assembly |
$13.50 |
|
|
| 28 | M-670157262 | Lh Pipe Assembly |
$13.37 |
|
|
| 29 | M-675000369 | Strap Collar |
$1.65 |
|
|
| 30 | M-670181076 | Bracket |
$46.08 |
|
|
| 31 | M-670175163 | Pressure Sensor |
$123.71 |
|
|
| 32 | M-675000969 | Nut |
$0.96 |
|
|
| 33 | M-670051107 | Screw |
$1.82 |
|
