The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670160000 | Cooling Module |
$2,093.01 |
|
|
| 2 | M-675001040 | Plate |
$1.27 |
|
|
| 3 | M-670005736 | Temperature Sensor |
$19.15 |
|
|
| 4 | M-670156538 | Air Duct |
$185.63 |
|
|
| 5 | M-675001053 | Screw |
$1.61 |
|
|
| 6 | M-670157041 | Bracket |
$29.16 |
|
|
| 7 | M-670157461 | Plate |
$13.20 |
|
|
| 8 | M-675001055 | Screw |
$2.26 |
|
|
| 9 | M-670157462 | Washer |
$15.74 |
|
|
| 10 | M-675001357 | Screw |
$4.00 |
|
|
| 11 | M-670158302 | Lh Bracket |
$27.95 |
|
|
| 12 | M-670158301 | Rh Bracket |
$27.95 |
|
|
| 14 | M-670156539 | Rh Side Air Duct |
$93.18 |
|
|
| 15 | M-670156540 | Lh Side Air Duct |
$93.18 |
|
|
| 16 | M-675000354 | Screw |
$2.72 |
|
|
| 17 | M-675001056 | Intercooler |
$277.96 |
|
|
| 18 | M-675001057 | Engine Intercool Radiator |
$315.28 |
|
|
| 19 | M-675000201 | Small Block. |
$9.42 |
|
|
| 20 | M-675000409 | Washer |
$2.49 |
|
|
| 21 | M-675001048 | Screw |
$0.71 |
|
|
| 22 | M-675001083 | Front Rh Grille |
$43.81 |
|
|
| 23 | M-675001082 | Front Lh Grille |
$43.81 |
|
|
| 24 | M-670157045 | Rh Bracket |
$31.68 |
|
|
| 25 | M-670157047 | Lh Bracket |
$30.30 |
|
|
| 26 | M-670160001 | Radiator |
$663.95 |
|
|
| 27 | M-675001213 | Electrofan Module |
$1,165.65 |
|
|
| 28 | M-675001449 | A.C. Condenser |
$634.49 |
|
|
| 29 | M-673012300 | Bleeding And Degassing Kit |
$54.77 |
|
