Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670160693 | Fuel Vapour Filter |
$179.41 |
|
|
| 2 | M-675001063 | Nut |
$1.23 |
|
|
| 3 | M-670156463 | Vent Pipe |
$85.39 |
|
|
| 4 | M-670156482 | Vapour Pipe |
$239.15 |
|
|
| 5 | M-670156090 | Hose |
$85.39 |
|
|
| 6 | M-670162028 | Solenoid Valve |
$39.31 |
|
|
| 7 | M-675001080 | Rubber |
$8.35 |
|
|
| 8 | M-670216936 | Solenoid Valve Bracket |
$39.50 |
|
|
| 9 | M-675000969 | Nut |
$0.98 |
|
|
| 10 | M-670157021 | Hose |
$68.59 |
|
|
| 11 | M-670157017 | Pipe From Solenoid Valve To |
$200.42 |
|
|
| 12 | M-670157016 | Hose |
$81.65 |
|
|
| 13 | M-670156097 | Vent Pipe |
$81.05 |
|
|
| 14 | M-670216935 | Solenoid Valve Bracket |
$39.50 |
|
|
| 15 | M-670157019 | Pipe From Sleeve Pipe To Val |
$200.42 |
|
|
| 16 | M-670157020 | Hose |
$68.59 |
|
|
| 17 | M-670051557 | Clip |
$4.98 |
|
|
| 18 | M-670157018 | Hose |
$68.59 |
|
|
| 19 | M-670156088 | Vapors Recycling Pipe |
$37.44 |
|
|
| 20 | M-670156483 | Hose |
$34.83 |
|
|
| 21 | M-670173070 | Bracket |
$28.32 |
|
|
| 22 | M-675001236 | Screw |
$1.37 |
|
|
| 29 | M-675001202 | Soundproofing Element |
$8.44 |
|
