Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670296462 | Air Conditioning Assembly |
$1,952.33 |
|
|
| 2 | M-670179044 | Shield For Water |
$180.36 |
|
|
| 3 | M-670178996 | Air Inlet Module |
$263.44 |
|
|
| 4 | M-670215189 | Cabin Air Filter |
$67.84 |
|
|
| 5 | M-675001186 | Nut |
$1.64 |
|
|
| 6 | M-675001364 | Washer |
$1.54 |
|
|
| 7 | M-675001115 | Screw |
$3.46 |
|
|
| 8 | M-670178477 | Clip |
$0.85 |
|
|
| 9 | M-673012115 | Thread Insert M6X50.5 |
$55.27 |
|
|
| 10 | M-673012116 | Wire Harness Fixing Clamps |
$11.04 |
|
|
| 11 | M-673014094 | Central Hvac Core |
$266.06 |
|
|
| 12 | M-673012111 | Air Inlet/Rec Kinematics |
$10.49 |
|
|
| 13 | M-673012105 | Kit Water Pipes |
$38.32 |
|
|
| 14 | M-673012106 | Heater Core W Pipes |
$344.64 |
|
|
| 15 | M-673012113 | Evaporator |
$444.06 |
|
|
| 16 | M-673012114 | Txv |
$107.60 |
|
|
| 17 | M-673012108 | Kit Sealings |
$71.67 |
|
|
| 18 | M-673012104 | A/C Wire Harness |
$149.44 |
|
|
| 19 | M-673012112 | Blower |
$408.09 |
|
|
| 20 | M-673012107 | Kit Drain Pipe |
$29.79 |
|
|
| 21 | M-673012117 | Front Drain Wall To Chassis |
$476.10 |
|
|
| 22 | M-673012301 | Kit Front Air Inlet/Rec Case |
$34.37 |
|
|
| 23 | M-670104418 | Actuator |
$63.20 |
|
|
| 24 | M-675001306 | Nut |
$1.13 |
|
|
| 25 | M-673009339 | Gasket Kit |
$45.28 |
|
|
| 26 | M-673012110 | Floor Duct |
$33.32 |
|
