The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-281187 | Crankcase/Lower Crank.Assemb |
$4,092.16 |
|
|
| 2 | M-14325340 | Tapered Threaded Plug 22X1.5 |
$7.23 |
|
|
| 3 | M-176421 | Centering Dowel |
$8.63 |
|
|
| 4 | M-219801 | Stud M12X1.75 Stem M10X1 |
$14.20 |
|
|
| 5 | M-133988 | Hex Nut M10X10.25.25X8 |
$1.75 |
|
|
| 6 | M-178348 | Machined Washer D.10.2-20X2. |
$3.57 |
|
|
| 7 | M-231623 | Socket Head Screw With Washe |
$1.09 |
|
|
| 8 | M-268886 | Engine Ground-Frame Ground B |
$72.75 |
|
|
| 9 | M-10304511 | Threaded Plug |
$3.02 |
|
|
| 10 | M-10263460 | Gasket 22- 28X 1.5 |
$1.69 |
|
|
| 11 | M-217968 | Stud M 14(X2) Stem M 11X1 |
$15.50 |
|
|
| 12 | M-185360 | Centring Dowel D.16X15 |
$6.26 |
|
|
| 13 | M-13547134 | Stud M10X1.25X20 Stem |
$2.40 |
|
|
| 14 | M-100052 | Centering Dowel |
$5.58 |
|
|
| 15 | M-177727 | Centering Dowel For Intake |
$5.58 |
|
|
| 16 | M-236143 | Gasket |
$9.89 |
|
|
| 17 | M-140071 | O-Ring D. 29.87- 8X 100 |
$1.67 |
|
|
| 18 | M-222316 | Right-Hand Engine Bracket |
$122.23 |
|
|
| 19 | M-11306934 | Bol For Motor Mount Assem |
$3.82 |
|
|
| 20 | M-11190574 | Tapered Rubber Washer 10.5-2 |
$1.67 |
|
|
| 21 | M-226572 | Engine Support Flexible Pad |
$409.28 |
|
|
| 22 | M-177018 | Nut For Rear Differential |
$2.52 |
|
|
| 23 | M-177764 | Nut |
$1.67 |
|
|
| 24 | M-196590 | Upper Engine Pad Protection |
$7.79 |
|
|
| 25 | M-198530 | Bracket. |
$132.29 |
|
|
| 26 | M-227525 | R.H. Heat Shield |
$127.12 |
|
|
| 27 | M-14058411 | Nut |
$1.67 |
|
|
| 28 | M-13833011 | Tebd Screw M5X10 |
$2.03 |
|
|
| 29 | M-255138 | Blow By Valve Assembly |
$70.64 |
|
|
| 30 | M-14303123 | Socket Head Screw M4X14 |
$1.48 |
|
