Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 2 | M-673000294 | Pedal Switch |
$42.30 |
|
|
| 4 | M-673000293 | Switch - Lumbar - 1R 4-Way - |
$50.49 |
|
|
| 7 | M-670035026 | Front Seat Memory Ecu |
$185.92 |
|
|
| 8 | M-673000319 | Bracket |
$18.84 |
|
|
| 9 | M-670008170 | Cpl Passenger Seat-Back Fram |
$665.82 |
|
|
| 11 | M-673000233 | Screw |
$5.04 |
|
|
| 12 | M-670006705 | Led Light |
$42.40 |
|
|
| 13 | M-673000234 | Bracket |
$13.75 |
|
|
| 14 | M-670006649 | Plate |
$6.17 |
|
|
| 15 | M-673000325 | Screw |
$2.10 |
|
|
| 16 | M-670006150 | Support |
$10.31 |
|
|
| 17 | M-670007533 | Front Bracket |
$22.08 |
|
|
| 18 | M-673000292 | R.H.Bracket |
$28.14 |
|
|
| 19 | M-670035027 | Comfort Seats Module |
$172.31 |
|
|
| 20 | M-673000299 | Bracket |
$8.13 |
|
|
| 24 | M-673006842 | Front Seatback Heat Element |
$59.43 |
|
|
| 25 | M-670006155 | Sbr Sensor |
$51.88 |
|
|
| 26 | M-673006841 | Front Cushion Heat Element |
$89.33 |
|
|
| 28 | M-673000326 | Rivet |
$1.72 |
|
