The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670034075 | Safety Release Lever |
$17.26 |
|
|
| 2 | M-675000604 | Screw |
$3.34 |
|
|
| 3 | M-670107349 | Engine Bonnet Opening Cable |
$38.59 |
|
|
| 4 | M-675000610 | Clip |
$1.00 |
|
|
| 6 | M-675000353 | Bowden Cable Fastening Clip |
$3.42 |
|
|
| 7 | M-670035105 | Bracket |
$8.10 |
|
|
| 8 | M-670153401 | Lh Bonnet Lock |
$60.44 |
|
|
| 9 | M-670153400 | Rh Bonnet Lock |
$60.44 |
|
|
| 10 | M-675000577 | Screw |
$1.39 |
|
|
| 11 | M-670033514 | Striker |
$103.57 |
|
|
| 12 | M-670036979 | Screw With Washer |
$2.11 |
|
