Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670217883 | Shw Brake Disc |
$350.94 |
|
|
| 2 | M-675000081 |
Screw
|
$5.08 |
|
|
| 3 | M-670005714 | Screw |
$6.78 |
|
|
| 4 | M-670214950 | Rh Front Caliper Black Ccc |
$884.29 |
|
|
| 5 | M-673012382 | Fr Brake Pads Kit M15X44B/M1 |
$552.34 |
|
|
| 6 | M-670155394 | Flexible Pipe To Front Calip |
$15.58 |
|
|
| 7 | M-670001817 | Right Front Flexible Brake P |
$4.57 |
|
|
| 8 | M-670032073 | Rh Front Caliper Rigid Pipe |
$14.66 |
|
|
| 9 | M-670106682 | R.H. Front Brake Disc Shield |
$62.11 |
|
|
| 10 | M-675000126 | Screw |
$1.66 |
|
|
| 11 | M-670039841 | Pipe |
$25.52 |
|
|
| 12 | M-198015 | Tie Rod |
$52.21 |
|
|
| 13 | M-673000025 | R.H.Rigid Pipe |
$83.24 |
|
|
| 14 | M-152954 | Bleeding Screw |
$40.36 |
|
|
| 15 | M-215666 | Cap |
$27.39 |
|
|
| 16 | M-198014 | Screw |
$22.55 |
|
|
| 17 | M-673000054 | Bracket And Screw |
$49.35 |
|
|
| 18 | M-182121 | Cap |
$76.61 |
|
|
| 19 | M-215664 | Cap |
$52.54 |
|
|
| 20 | M-215663 | Cap |
$52.54 |
|
|
| 21 | M-675000281 | Gasket On Pillar |
$3.44 |
|
|
| 22 | M-670039674 | Clip |
$2.45 |
|
|
| 23 | M-675000272 | Retaining Clip |
$5.14 |
|
|
| 24 | M-670007373 | Bracket |
$8.85 |
|
|
| 25 | M-675000126 | Screw |
$1.66 |
|
|
| 27 | M-675000276 | Plate |
$0.96 |
|
|
| 28 | M-670037128 | Rh Brake Pipe Bracket |
$3.70 |
|
|
| 29 | M-675000621 | Screw (M6X18) |
$0.89 |
|
