The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670104057 | Cpl Front Differential |
$1,970.48 |
|
|
| 2 | M-14306534 | Screw |
$2.48 |
|
|
| 3 | M-809761 | Bracket |
$169.39 |
|
|
| 4 | M-670107695 | Front Drive Shaft |
$664.69 |
|
|
| 5 | M-670003772 | Plate |
$3.76 |
|
|
| 6 | M-675000583 | Screw |
$2.48 |
|
|
| 7 | M-670152631 | Heat Shield |
$53.60 |
|
|
| 8 | M-675000102 | Screw |
$2.69 |
|
|
| 10 | M-675000384 | Screw |
$5.20 |
|
|
| 13 | M-675000102 | Screw |
$2.69 |
|
|
| 14 | M-670107945 | Lh Axle Shaft |
$821.21 |
|
|
| 17 | M-670107944 | Rh Axle Shaft |
$672.19 |
|
|
| 18 | M-675000386 | Screw |
$3.78 |
|
|
| 19 | M-675000385 | Screw |
$3.72 |
|
|
| 20 | M-670160290 | Transfer Case Control Unit |
$605.72 |
|
|
| 21 | M-673009049 | Hexalobular Screw |
$5.79 |
|
|
| 23 | M-675000138 | Nut |
$9.10 |
|
|
| 24 | M-809763 | Oil Pipe |
$46.89 |
|
|
| 26 | M-46328688 | Flange Bolt |
$3.11 |
|
|
| 28 | M-673008007 | O-Ring |
$5.26 |
|
|
| 29 | M-673008008 | Snap-Ring |
$5.68 |
|
