Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 2 | M-673000294 | Pedal Switch |
$42.63 |
|
|
| 3 | M-670186720 | Rh Seat Adjustment Switch Lh |
$76.74 |
|
|
| 4 | M-670173855 | Switch |
$72.32 |
|
|
| 5 | M-673000320 | Blower Heat And Cool |
$278.74 |
|
|
| 6 | M-673000321 | Blower Heat And Cool |
$230.50 |
|
|
| 7 | M-670035026 | Front Seat Memory Ecu |
$187.40 |
|
|
| 8 | M-673000319 | Bracket |
$18.99 |
|
|
| 9 | M-670008170 | Cpl Passenger Seat-Back Fram |
$671.12 |
|
|
| 11 | M-673000233 | Screw |
$5.08 |
|
|
| 12 | M-670006705 | Led Light |
$42.74 |
|
|
| 13 | M-673000234 | Bracket |
$13.86 |
|
|
| 14 | M-670006649 | Plate |
$6.22 |
|
|
| 15 | M-673000325 | Screw |
$2.11 |
|
|
| 16 | M-670006150 | Support |
$10.39 |
|
|
| 17 | M-670007533 | Front Bracket |
$22.26 |
|
|
| 18 | M-673000292 | R.H.Bracket |
$28.37 |
|
|
| 19 | M-670035027 | Comfort Seats Module |
$173.68 |
|
|
| 20 | M-673000299 | Bracket |
$8.19 |
|
|
| 21 | M-670006706 | Hard Cover Plastic |
$39.71 |
|
|
| 23 | M-673008282 | Front Seat Backrest Heater C |
$166.40 |
|
|
| 24 | M-673006842 | Front Seatback Heat Element |
$59.91 |
|
|
| 25 | M-670006155 | Sbr Sensor |
$52.29 |
|
|
| 26 | M-673006841 | Front Cushion Heat Element |
$90.04 |
|
|
| 27 | M-670008217 | Front Seat Cushion Heater Cp |
$179.28 |
|
|
| 28 | M-673000326 | Rivet |
$1.74 |
|
