The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670154492 | Cpl Rh Catalytic Converter |
€2.936,64 |
|
|
| 2 | M-670154490 | Cpl Lh Catalytic Converter |
€2.526,20 |
|
|
| 3 | M-675000060 | Collar |
€25,21 |
|
|
| 5 | M-670104017 | Rh Bracket |
€75,72 |
|
|
| 6 | M-670104016 | Lh Bracket |
€69,83 |
|
|
| 7 | M-675000397 | Screw |
€7,82 |
|
|
| 8 | M-675000780 | Nut |
€2,02 |
|
|
| 9 | M-675000052 | Gasket |
€7,36 |
|
|
| 11 | M-670104046 | Lambda Sensor |
€104,92 |
|
|
| 12 | M-670104045 | Rear Lambda Sensor |
€104,92 |
|
|
| 13 | M-670005126 | Clip |
€0,95 |
|
|
| 14 | M-670002259 | Bracket |
€5,61 |
|
|
| 15 | M-675000134 | Clip |
€5,06 |
|
|
| 16 | M-670104045 | Rear Lambda Sensor |
€104,92 |
|
|
| 17 | M-675000143 | Clip |
€0,84 |
|
|
| 18 | M-670003739 | Clip |
€2,09 |
|
|
| 19 | M-670104528 | Retaining Clip |
€1,46 |
|
|
| 20 | M-670106995 | Retaining Clip |
€1,46 |
|
|
| 21 | M-675000143 | Clip |
€0,84 |
|
|
| 22 | M-670104048 | Bracket Assembly |
€12,42 |
|
|
| 23 | M-670009081 | Fastening Clip |
€8,65 |
|
|
| 26 | M-675000257 | Screw |
€5,15 |
|
|
| 27 | M-675000779 | Nut |
€2,39 |
|
|
| 28 | M-670105160 | Retaining Clip |
€1,25 |
|
|
| 29 | M-670002259 | Bracket |
€5,61 |
|
