The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670109556 | Rh Intercooler |
€365,50 |
|
|
| 2 | M-670031962 | Rh Intercooler Bracket |
€27,32 |
|
|
| 3 | M-670300486 | INTERCOOL AIR CONVEYOR |
€51,48 |
|
|
| 4 | M-670009576 | Intercooler Elastic Support |
€5,61 |
|
|
| 5 | M-670009556 | Radiator Support Fastening B |
€2,61 |
|
|
| 6 | M-670031963 | Rh Lower Intercooler Bracket |
€51,34 |
|
|
| 7 | M-670109553 | Lh Intercooler M161 V8 |
€365,50 |
|
|
| 8 | M-670300489 | Lh Side Air Duct |
€47,35 |
|
|
| 9 | M-670031960 | Lh Lower Intercooler Bracket |
€58,14 |
|
|
| 10 | M-670031961 | Lh Intercooler Bracket |
€31,00 |
|
|
| 11 | M-670103764 | Pipe Between Intercooler And |
€209,10 |
|
|
| 12 | M-675000014 | Pressure Sensor |
€103,20 |
|
|
| 13 | M-675000016 | Rubber Bushing |
€4,88 |
|
|
| 14 | M-675000017 | Spacer |
€6,90 |
|
|
| 15 | M-670103766 | Sleeve From Turbine To Rh In |
€206,55 |
|
|
| 16 | M-670103765 | Sleeve |
€337,45 |
|
|
| 17 | M-670103767 | Sleeve From Turbine To Lh In |
€212,50 |
|
|
| 18 | M-670006209 | Gasket For Air Delivery Pipe |
€14,08 |
|
|
| 19 | M-675000190 | Screw |
€2,49 |
|
|
| 20 | M-670103782 | Rh Bracket |
€15,36 |
|
|
| 23 | M-675000375 | Screw |
€0,63 |
|
|
| 25 | M-675000376 | Screw |
€1,17 |
|
|
| 29 | M-670005919 | Retaining Clip |
€3,13 |
|
|
| 30 | M-675000087 | Screw |
€3,01 |
|
|
| 31 | M-675000354 | Screw |
€2,29 |
|
|
| 32 | M-670009712 | Washer |
€9,48 |
|
|
| 34 | M-670039441 | Washer |
€11,13 |
|
|
| 36 | M-670104113 | Vapour Pipe |
€36,47 |
|
|
| 37 | M-675000718 | Washer |
€1,89 |
|
|
| 40 | M-670101334 | Clip |
€2,61 |
|
|
| 41 | M-675000685 | Collar |
€6,44 |
|
|
| 42 | M-14464786 | O-Ring |
€29,07 |
|
