Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670153172 | Rear Chassis Assembly |
$2,041.87 |
|
|
| 2 | M-670035577 | Screw ˇ |
$7.21 |
|
|
| 3 | M-670035578 | Screw ˇ |
$8.58 |
|
|
| 6 | M-670032009 | Lh Bracket |
$14.12 |
|
|
| 7 | M-670032010 | Dh Bracket |
$14.12 |
|
|
| 8 | M-670039843 | Screw |
$2.37 |
|
|
| 11 | M-670108933 | Rear End-Stop Absorb |
$123.35 |
|
