Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670154492 | Cpl Rh Catalytic Converter |
$3,382.61 |
|
|
| 2 | M-670154490 | Cpl Lh Catalytic Converter |
$2,924.65 |
|
|
| 3 | M-675000060 | Collar |
$28.82 |
|
|
| 5 | M-670104017 | Rh Bracket |
$87.21 |
|
|
| 6 | M-670104016 | Lh Bracket |
$79.84 |
|
|
| 7 | M-675000397 | Screw |
$9.01 |
|
|
| 8 | M-675000780 | Nut |
$2.38 |
|
|
| 9 | M-675000052 | Gasket |
$8.42 |
|
|
| 11 | M-670104046 | Lambda Sensor |
$120.80 |
|
|
| 12 | M-670104045 | Rear Lambda Sensor |
$120.80 |
|
|
| 13 | M-670005126 | Clip |
$1.09 |
|
|
| 14 | M-670002259 | Bracket |
$6.62 |
|
|
| 15 | M-675000134 | Clip |
$5.87 |
|
|
| 16 | M-670104045 | Rear Lambda Sensor |
$120.80 |
|
|
| 17 | M-675000143 | Clip |
$0.97 |
|
|
| 18 | M-670003739 | Clip |
$2.43 |
|
|
| 19 | M-670104528 | Retaining Clip |
$1.69 |
|
|
| 20 | M-670106995 | Retaining Clip |
$1.69 |
|
|
| 21 | M-675000143 | Clip |
$0.97 |
|
|
| 22 | M-670104048 | Bracket Assembly |
$14.20 |
|
|
| 23 | M-670009081 | Fastening Clip |
$9.89 |
|
|
| 24 | M-670108354 | Collar Bracket Rh Hot-End |
$52.80 |
|
|
| 25 | M-670108353 | Collar Bracket Lh Hot-End |
$140.60 |
|
|
| 26 | M-675000257 | Screw |
$5.93 |
|
|
| 27 | M-675000779 | Nut |
$2.79 |
|
|
| 28 | M-670105160 | Retaining Clip |
$1.45 |
|
|
| 29 | M-670002259 | Bracket |
$6.62 |
|
