Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-287732 | Valve |
$73.02 |
|
|
| 2 | M-231617 | Socket Head Screw With Washe |
$2.39 |
|
|
| 3 | M-294143 | Wg-Dv Control Pipes |
$105.65 |
|
|
| 4 | M-231616 | Screw |
$2.03 |
|
|
| 5 | M-13125070 | Collar |
$1.60 |
|
|
| 6 | M-797774 | Lh Wg-Dv Control Pipe |
$379.78 |
|
|
| 7 | M-231616 | Screw |
$2.03 |
|
|
| 8 | M-299445 | Pipe From Solenoid Valve To |
$30.56 |
|
|
| 9 | M-315769 | On/Off Solenoid Valve |
$63.58 |
|
|
| 10 | M-14304624 | Screw |
$0.95 |
|
|
| 11 | M-12601174 | Washer |
$1.55 |
|
|
| 12 | M-756928 | Rh Wg-Dv Control Pipe |
$352.18 |
|
|
| 13 | M-297635 | Upper Fixed Pipe On Guard Be |
$42.07 |
|
|
| 14 | M-295314 | Shield |
$37.42 |
|
|
| 15 | M-231619 | Socket Head Screw With Washe |
$2.39 |
|
|
| 16 | M-782715 | Vacuum Pump Pipe |
$276.03 |
|
|
| 17 | M-303259 | Vacuum Pump (V8) |
$571.10 |
|
|
| 18 | M-231628 | Screw |
$2.39 |
|
|
| 19 | M-288906 | Bracket |
$22.77 |
|
|
| 20 | M-287562 | Bracket |
$41.01 |
|
|
| 21 | M-222826 | Clip |
$5.60 |
|
|
| 22 | M-231616 | Screw |
$2.03 |
|
|
| 23 | M-297636 | Lower Fixed Pipe On Guard Be |
$64.50 |
|
|
| 24 | M-292206 | Pipe Retaining Clip |
$3.56 |
|
|
| 25 | M-295436 | Vacuum Pump Gasket |
$29.67 |
|
