Diagram image not available
The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-293643 | Return Hose Water From R.H.T |
$152.29 |
|
|
| 2 | M-278398 | Threaded Union |
$94.43 |
|
|
| 3 | M-11270260 | Gasket |
$1.10 |
|
|
| 4 | M-319864 | Filler Neck |
$13.71 |
|
|
| 5 | M-10261060 | Gasket 12- 16X 1.5 |
$1.13 |
|
|
| 6 | M-290011 | Return Hose Water From L.H.T |
$162.76 |
|
|
| 7 | M-322985 | Water Delivery Pipe To Rh Tu |
$117.08 |
|
|
| 8 | M-231617 | Socket Head Screw With Washe |
$2.39 |
|
|
| 9 | M-275034 | Union |
$45.62 |
|
|
| 10 | M-10280060 | Gasket |
$1.09 |
|
|
| 11 | M-290014 | Delivery Hose Water From L.H |
$169.43 |
|
|
| 12 | M-292744 | Delivery Hose Oil From R.H.T |
$142.77 |
|
|
| 13 | M-231617 | Socket Head Screw With Washe |
$2.39 |
|
|
| 14 | M-319864 | Filler Neck |
$13.71 |
|
|
| 15 | M-10261060 | Gasket 12- 16X 1.5 |
$1.13 |
|
|
| 16 | M-292745 | Delivery Hose Oil From L.H.T |
$214.16 |
|
|
| 17 | M-322991 | Oil Recovery Pipe From Rh Tu |
$133.26 |
|
|
| 18 | M-248334 | Screw |
$2.86 |
|
|
| 19 | M-278390 | L.H.Pipe Oil Recovery |
$113.27 |
|
|
| 20 | M-271457 | Gasket On Oil Drain Pipe |
$3.46 |
|
|
| 21 | M-287722 | O-R Gasket |
$2.31 |
|
|
| 22 | M-14456981 | O-Ring D. 10.78X2.5 |
$1.72 |
|
|
| 23 | M-14456981 | O-Ring D. 10.78X2.5 |
$1.72 |
|
|
| 24 | M-14456981 | O-Ring D. 10.78X2.5 |
$1.72 |
|
|
| 25 | M-14456981 | O-Ring D. 10.78X2.5 |
$1.72 |
|
