The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-743834 | Rh Turbocharger |
$6,083.06 |
|
|
| 2 | M-292736 | Gasket |
$75.82 |
|
|
| 3 | M-210971 | S-Lock.Thread.Flanged Hex.Nu |
$5.27 |
|
|
| 4 | M-743835 | Lh Turbocharger |
$5,686.82 |
|
|
| 5 | M-670104134 | Rh Exhaust Manifold Heat Shi |
$81.38 |
|
|
| 6 | M-670002874 | Lh Exhaust Manifold Heat Shi |
$80.64 |
|
|
| 9 | M-802783 | Compressor Input Flange |
$184.99 |
|
|
| 10 | M-760998 | Compressor Input Flange |
$147.78 |
|
|
| 11 | M-231619 | Socket Head Screw With Washe |
$2.39 |
|
|
| 12 | M-330933 | Compressor Gasket |
$29.97 |
|
|
| 40 | M-790330 | Anti-Heat Shield |
$86.80 |
|
|
| 41 | M-288179 | Bracket |
$6.41 |
|
|
| 42 | M-233600 | Screw |
$2.29 |
|
