The parts list is available below.
Be aware: Two same spot numbers are selected, for example left and right.
| # | S | Part nr | Description | Price | Add |
|---|---|---|---|---|---|
| 1 | M-670103670 | R.H. Intercooler |
$430.19 |
|
|
| 2 | M-670031962 | Rh Intercooler Bracket |
$32.13 |
|
|
| 3 | M-670300486 | INTERCOOL AIR CONVEYOR |
$57.26 |
|
|
| 4 | M-670009576 | Intercooler Elastic Support |
$6.60 |
|
|
| 5 | M-670009556 | Radiator Support Fastening B |
$3.19 |
|
|
| 6 | M-670031963 | Rh Lower Intercooler Bracket |
$61.10 |
|
|
| 7 | M-670103671 | L.H. Intercooler |
$409.57 |
|
|
| 8 | M-670300489 | Lh Side Air Duct |
$55.69 |
|
|
| 9 | M-670031960 | Lh Lower Intercooler Bracket |
$69.21 |
|
|
| 10 | M-670031961 | Lh Intercooler Bracket |
$36.45 |
|
|
| 11 | M-670103764 | Pipe Between Intercooler And |
$246.53 |
|
|
| 12 | M-675000014 | Pressure Sensor |
$122.23 |
|
|
| 13 | M-675000016 | Rubber Bushing |
$5.80 |
|
|
| 14 | M-675000017 | Spacer |
$8.22 |
|
|
| 15 | M-670103766 | Sleeve From Turbine To Rh In |
$243.58 |
|
|
| 16 | M-670103765 | Sleeve |
$351.62 |
|
|
| 17 | M-670103767 | Sleeve From Turbine To Lh In |
$220.99 |
|
|
| 18 | M-670006209 | Gasket For Air Delivery Pipe |
$16.55 |
|
|
| 19 | M-675000190 | Screw |
$2.93 |
|
|
| 20 | M-670103782 | Rh Bracket |
$18.07 |
|
|
| 23 | M-675000375 | Screw |
$0.77 |
|
|
| 25 | M-675000376 | Screw |
$1.39 |
|
|
| 29 | M-670005919 | Retaining Clip |
$3.68 |
|
|
| 30 | M-675000087 | Screw |
$3.57 |
|
|
| 31 | M-675000354 | Screw |
$2.72 |
|
|
| 32 | M-670009712 | Washer |
$11.15 |
|
|
| 34 | M-670039441 | Washer |
$13.10 |
|
|
| 36 | M-670104113 | Vapour Pipe |
$42.88 |
|
|
| 37 | M-675000718 | Washer |
$2.24 |
|
|
| 40 | M-670101334 | Clip |
$3.08 |
|
|
| 41 | M-675000685 | Collar |
$7.58 |
|
|
| 42 | M-14464786 | O-Ring |
$34.19 |
|
